•  As its name, this type of bearing's needles roll freely in ONE direction, but lock to transmit torque when the rotation of the shaft is reversed. It is also known as drawn-cup roller clutches. An arrow on the lip indicates the rotational direction that locks the bearings.
•  Single-row bearings do not support loads from any direction. To support radial loads, use with CLI needle roller bearings. Triple-row bearings support radial loads.
•  The miniature ONE-WAY clutch consists of drawn cup, rollers, cage, and springs.The drawn cup, made of carburized steel sheet, has a unique structure: a protruding portion, which serves as a stopper of rotation on the outside surface at O.D. side, and a cam on the outer ring at bore side are provided.
•  One Way Overrunning Sprag Freewheel Cam Clutch Bearings also called Overrunning Clutches, Cam Clutches, Sprag Clutches, One Way Clutches) are directional couplings, which means they are engaged and disengaged automatically, depending on the relative direction of rotation of the driving nad driven sides.
•  Please contact CLI BEARING sales to get more detailed information about this type of bearings...


-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

  → One Way Clutch Bearings
HF / HF-KF / HF-R / HF-KF-R
( METRIC size )


→ One Way Clutch Bearings
HFL / HFL-KF / HFL-R / HFL-KF-R

( METRIC size )


    One Way Clutch Bearings FC ( METRIC size ) →         One Way Clutch Bearings FCB ( METRIC size )
  → One Way Clutch Bearings
EWC / EWC-A / EWC-C ( METRIC size )


→ One Way Clutch Bearings
1WC / IWC
( METRIC size )




    One Way Clutch Bearings RC / RC-FS
( INCH size ) →


One Way Clutch Bearings RCB / RCB-FS

( INCH size ) →


  OWC-GXZ / OWC-GXLZ / OWC-GXRZ
Origin One-way Clutches ( METRIC size )
        OWC6128.4GXLZ / OWC6128.4GXRZ / OWC8148.4GXLZ / OWC8148.4GXRZ
Origin One-way Clutch ( METRIC size )

    CSK / CSK-2RS ( METRIC size ) Sprag Keyway Type One Way Clutch Bearings, One Way Overrunning Sprag Freewheel Cam Clutch Bearings →         CSK..P / CSK..P-2RS ( METRIC size ) Sprag Keyway Type One Way Clutch Bearings, One Way Overrunning Sprag Freewheel Cam Clutch Bearings →
  CSK..PP ( METRIC size ) Sprag Keyway Type One Way Clutch Bearings, One Way Overrunning Sprag Freewheel Cam Clutch Bearings


-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

HF / HF-KF / HF-R / HF-KF-R,
One-Way Roller Clutch Bearings for
shaft sizes from
3 mm to 35 mm
CLI Bearing No. Seal Type Bore Dia Outer Dia Width Md per nGW nGA
(Fw) (D) (C)
HF0306 Open 3 mm 6.5 mm 6 mm 0.18 Nm 45000 1/min 8000 1/min
HF0306-KF Open 3 mm 6,5 mm 6 mm 0,18 Nm 45000 1/min 8000 1/min
HF0306-KF-R Open 3 mm 6,5 mm 6 mm 0,06 Nm 45000 1/min 8000 1/min
HF0406 Open 4 mm 8 mm 6 mm 0,34 Nm 34000 1/min 8000 1/min
HF0406-KF Open 4 mm 8 mm 6 mm 0,34 Nm 34000 1/min 8000 1/min
HF0406-KF-R Open 4 mm 8 mm 6 mm 0,1 Nm 34000 1/min 8000 1/min
HF0612 Open 6 mm 10 mm 12 mm 1,76 Nm 23000 1/min 13000 1/min
HF0612-KF Open 6 mm 10 mm 12 mm 1,76 Nm 23000 1/min 13000 1/min
HF0612-KF-R Open 6 mm 10 mm 12 mm 0,6 Nm 23000 1/min 13000 1/min
HF0612-R Open 6 mm 10 mm 12 mm 0,6 Nm 23000 1/min 13000 1/min
HF0812 Open 8 mm 12 mm 12 mm 3,15 Nm 17000 1/min 12000 1/min
HF0812-KF Open 8 mm 12 mm 12 mm 3,15 Nm 17000 1/min 12000 1/min
HF0812-KF-R Open 8 mm 12 mm 12 mm 1 Nm 17000 1/min 12000 1/min
HF0812-R Open 8 mm 12 mm 12 mm 1 Nm 17000 1/min 12000 1/min
HF1012 Open 10 mm 14 mm 12 mm 5,3 Nm 14000 1/min 11000 1/min
HF1012-KF Open 10 mm 14 mm 12 mm 5,3 Nm 14000 1/min 11000 1/min
HF1216 Open 12 mm 18 mm 16 mm 12,2 Nm 11000 1/min 8000 1/min
HF1416 Open 14 mm 20 mm 16 mm 17,3 Nm 9500 1/min 8000 1/min
HF1616 Open 16 mm 22 mm 16 mm 20,5 Nm 8500 1/min 7500 1/min
HF1816 Open 18 mm 24 mm 16 mm 24,1 Nm 7500 1/min 7500 1/min
HF2016 Open 20 mm 26 mm 16 mm 28,5 Nm 7000 1/min 6500 1/min
HF2520 Open 25 mm 32 mm 20 mm 66 Nm 5500 1/min 5500 1/min
HF3020 Open 30 mm 37 mm 20 mm 90 Nm 4500 1/min 4500 1/min
HF3520 Open 35 mm 42 mm 20 mm 121 Nm 3900 1/min 3900 1/min

FC One-Way Clutch Bearings,
One-Way Needle-Roller Bearing Clutches for
shaft sizes from
8 mm to 30 mm
CLI
Bearing No.
Dimensions
( Fw x D x C )
Torque Shaft Weight
Metric (mm) (N.m) (RPM) (g)
FC-6 6x10x12 - - 6
FC-8 8 x 14 x 12 4.42 21000 7
FC-10 10 x 16 x 12 5.82 19000 9
FC-12 12 x 18 x 16 14 19000 12
FC-16 16 x 22 x 16 21.7 14000 18
FC-20 20 x 26 x 16 32.6 11000 21
FC-25 25 x 32 x 20 71 8700 34
FC-30 30 x 37 x 20 99.1 7300 42

RC / RC-FS
One Way Roller Clutch Bearing Bearings for
shaft sizes from
0.125 inch to 1.000 inch
CLI
Bearing No.
Dimensions ( Fw x D x C ) Torque Shaft Weight
Imperial (inch) (N.m) (RPM) (g)
RC-02 0.1250 x 0.2810 x 0.2500 0.323 34000 1.00
RC-040708 0.2500 x 0.4375 x 0.5000 2.02 20000 3.20
RC-040708-FS 0.2500 x 0.4375 x 0.5000 2.02 2000 3.32
RC-061008 0.3750 x 0.6250 x 0.5000 5.45 18000 7.23
RC-061008-FS 0.3750 x 0.6250 x 0.5000 5.45 18000 7.09
RC-081208 0.5000 x 0.7500 x 0.5000 8.85 17000 9.36
RC-081208-FS 0.5000 x 0.7500 x 0.5000 8.85 17000 9.60
RC-101410 0.6250 x 0.8750 x 0.6250 16.8 14000 13.14
RC-101410-FS 0.6250 x 0.8750 x 0.6250 16.8 14000 14.62
RC-121610 0.7500 x 1.0000 x 0.6250 23.3 12000 15.72
RC-121610-FS 0.7500 x 1.0000 x 0.6250 23.3 12000 16.50
RC-162110 1.0000 x 1.3100 x 0.6250 49.6 8700 25.62
RC-162110-FS 1.0000 x 1.3130 x 0.6250 49.6 8700 26.00

1WC / IWC
Miniature One-Way Clutch Bearings for
shaft sizes from 6 mm
 to 12 mm
CLI Bearing No. Seal Type ID OD1 OD2 Width Torque Capacity Weight
(Fw) (D1) (D2) (C) (g)
1WC0608 Open 6 mm 10 mm 10.4 mm 8 mm 0.44 2
1WC0612 Open 6 mm 10 mm 10.4 mm 12 mm 0.88 3
1WC0812 Open 8 mm 14.2 mm 15 mm 12 mm 1.96 7
1WC0815 Open 8 mm 14.2 mm 15 mm 14.5 mm 2.65 8
1WC1012 Open 10 mm 16 mm 17 mm 12 mm 2.35 8
1WC1216 Open 12 mm 18 mm 19 mm 16 mm 6.28 12


OWC..GXLZ
Miniature One Way Clutch Bearings with Counter-Clockwise Rotation Direction

METRIC Sizes for shaft sizes from  3 mm to 10 mm
CLI Dimension (mm) Torque Rating Backlash Weight (g)
Bearing No. d D1 B (N.m)
OWC307GXLZ 3 7.2 5.4 0.13 4 1.10
OWC408GXLZ 4 8 6 0.15 4 1.70
OWC410GXLZ 4 10 5.4 0.30 3.5 2.15
OWC511GXLZ 5 11 5.4 0.60 3 2.35
OWC610GXLZ 6 10.2 8 0.54 3 2.55
OWC612GXLZ 6 12 5.4 0.80 3 2.75
OWC612GXLZ-W8.4 6 12 8.4 0.80 3 2.82
OWC812GXLZ 8 12.2 8 0.73 3 3.30
OWC814GXLZ 8 14 5.4 1.10 2 3.37
OWC814GXLZ-W8.4 8 14.3 8.4 1.47 3 3.80
OWC1016GXLZ 10 16 5.4 1.50 1 4.03

CSK
Sprag Keyway Type One Way Clutch Bearings,
One Way Overrunning Sprag Freewheel Cam Clutch Bearings for
shaft sizes from
 8 mm to 40 mm
CLI Dimension
(mm)
Torque Limiting Speed
(RPM)
Load Rating Weight
Bearing No. d D L N.m Dynamic(C) Static(Co) (KN) Kg
CSK8 8 22 9 2.5 15000 3.28 0.86 0.015
CSK12 12 32 10 9.3 10000 6.1 2.77 0.04
CSK15 15 35 11 17 8400 7.4 3.42 0.06
CSK17 17 40 12 30 7350 7.9 3.8 0.07
CSK20 20 47 14 50 6000 9.4 4.46 0.11
CSK25 25 52 15 85 5200 10.7 5.46 0.14
CSK30 30 62 16 138 4200 11.7 6.45 0.21
CSK35 35 72 17 175 3600 12.6 7.28 0.3
CSK40 40 80 22 325 3000 15.54 12.25 0.5
CSK6003 17 35 10 15       0.055
CSK6004 20 42 12 28       0.065
CSK6005 25 47 14 78       0.1
CSK6304 20 52 15 85       0.18
CSK6305 25 62 17 145       0.26
CSK6306 30 72 19 205       0.415

CSK-2RS
Sprag Keyway Type One Way Clutch Bearings,
One Way Overrunning Sprag Freewheel Cam Clutch Bearings for
shaft sizes from
 8 mm to 40 mm
CLI Dimension
(mm)
Torque Limiting Speed
(RPM)
Load Rating Weight
Bearing No. d D L N.m Dynamic(C) Static(Co) (KN) Kg
CSK8-2RS 8 22 9 2.5 15000 3.28 0.86 0.015
CSK12-2RS 12 32 14 9.3 10000 6.1 2.77 0.05
CSK15-2RS 15 35 16 17 8400 7.4 3.42 0.07
CSK17-2RS 17 40 17 30 7350 7.9 3.8 0.09
CSK20-2RS 20 47 19 50 6000 9.4 4.46 0.145
CSK25-2RS 25 52 20 85 5200 10.7 5.46 0.175
CSK30-2RS 30 62 21 138 4200 11.7 6.45 0.27
CSK35-2RS 35 72 22 175 3600 12.6 7.28 0.4
CSK40-2RS 40 80 27 325 3000 15.54 12.25 0.6
HFL / HFL-KF / HFL-R / HFL-KF-R,
One-Way Roller Clutch Bearings for
shaft sizes from
 3 mm to 35 mm
CLI Bearing No. Seal Type Bore Dia Outer Dia Width Md per nGW nGA
(Fw) (D) (C)
HFL0308-KF Open 3 mm 6,5 mm 8 mm 0,18 Nm 45000 1/min 8000 1/min
HFL0308-KF-R Open 3 mm 6,5 mm 8 mm 0,06 Nm 45000 1/min 8000 1/min
HFL0408-KF Open 4 mm 8 mm 8 mm 0,34 Nm 34000 1/min 8000 1/min
HFL0408-KF-R Open 4 mm 8 mm 8 mm 0,1 Nm 34000 1/min 8000 1/min
HFL0606-KF-R Open 6 mm 10 mm 6 mm 0,5 Nm 23000 1/min 13000 1/min
HFL0615 Open 6 mm 10 mm 15 mm 1,76 Nm 23000 1/min 13000 1/min
HFL0615-KF Open 6 mm 10 mm 15 mm 1,76 Nm 23000 1/min 13000 1/min
HFL0615-KF-R Open 6 mm 10 mm 15 mm 0,6 Nm 23000 1/min 13000 1/min
HFL0615-R Open 6 mm 10 mm 15 mm 0,5 Nm 23000 1/min 13000 1/min
HFL0806-KF-R Open 8 mm 12 mm 6 mm 0,7 Nm 17000 1/min 12000 1/min
HFL0822 Open 8 mm 12 mm 22 mm 3,15 Nm 17000 1/min 12000 1/min
HFL0822-KF Open 8 mm 12 mm 22 mm 3,15 Nm 17000 1/min 12000 1/min
HFL0822-KF-R Open 8 mm 12 mm 22 mm 1 Nm 17000 1/min 12000 1/min
HFL0822-R Open 8 mm 12 mm 22 mm 1 Nm 17000 1/min 12000 1/min
HFL1022 Open 10 mm 14 mm 22 mm 5,3 Nm 14000 1/min 11000 1/min
HFL1226 Open 12 mm 18 mm 26 mm 12,2 Nm 11000 1/min 8000 1/min
HFL1426 Open 14 mm 20 mm 26 mm 17,3 Nm 9500 1/min 8000 1/min
HFL1626 Open 16 mm 22 mm 26 mm 20,5 Nm 8500 1/min 7500 1/min
HFL1826 Open 18 mm 24 mm 26 mm 24,1 Nm 7500 1/min 7500 1/min
HFL2026 Open 20 mm 26 mm 26 mm 28,5 Nm 7000 1/min 6500 1/min
HFL2530 Open 25 mm 32 mm 30 mm 66 Nm 5500 1/min 5500 1/min
HFL3030 Open 30 mm 37 mm 30 mm 90 Nm 4500 1/min 4500 1/min
HFL3530 Open 35 mm 42 mm 30 mm 121 Nm 3900 1/min 3900 1/min

FCB One-Way Clutch Bearings,
One-Way Needle-Roller Bearing Clutches for
shaft sizes from
8 mm to 30 mm
CLI
Bearing No.
Dimensions
( Fw x D x C )
Torque Shaft Weight
Metric (mm) (N.m) (RPM) (g)
FCB-8 8 x 14 x 20 4.42 21000 11
FCB-10 10 x 16 x 20 5.82 19000 13
FCB-12 12 x 18 x 26 14 19000 18
FCB-16 16 x 22 x 26 20.59 14000 24
FCB-20 20 x 26 x 26 32.6 11000 28
FCB-25 25 x 32 x 30 71 8700 48
FCB-30 30 x 37 x 30 99.1 7300 54

RCB / RCB-FS
One Way Roller Clutch Bearings for
shaft sizes from
0.375 inch to 1.000 inch
CLI
Bearing No.
Dimensions ( FW x D x C ) Torque Shaft Weight
Imperial (inch) (N.m) (RPM) (g)
RCB-061014 0.3750 x 0.6250 x 0.8750 5.45 18000 12.86
RCB-061014-FS 0.3750 x 0.6250 x 0.8750 5.45 18000 12.90
RCB-081214 0.5000 x 0.7500 x 0.8750 8.85 17000 16.14
RCB-081214-FS 0.5000 x 0.7500 x 0.8750 8.85 17000 16.67
RCB-101416 0.6250 x 0.8750 x 1.0000 16.8 14000 22.58
RCB-101416-FS 0.6250 x 0.8750 x 1.0000 16.8 14000 23.24
RCB-121616 0.7500 x 1.0000 x 1.0000 23.3 12000 25.25
RCB-121616-FS 0.7500 x 1.0000 x 1.0000 23.3 12000 27.11
RCB-162117 1.0000 x 1.3130 x 1.0630 49.6 8700 41.52
RCB-162117-FS 1.0000 x 1.3130 x 1.0630 49.6 8700 45.00

EWC / EWC-A / EWC-C
Miniature One-Way Clutch Bearings for
shaft sizes from
4 mm to 10 mm
CLI
Bearing No.
CLI
Bearing No.
ID OD1 OD2 Width Torque
Capacity
Weight
(Fw) (D1) (D2) (C) (g)
EWC0406A SS-EWC0406A 4 mm 8 mm 8.4 mm 6 mm 0.08 1
EWC0406C SS-EWC0406C 4 mm 8 mm 8.4 mm 6 mm 0.15 1
EWC0606XC SS-EWC0606XC 6 mm 10 mm 10.4 mm 6 mm 0.19 1.4
EWC0608A SS-EWC0608A 6 mm 10 mm 10.4 mm 8 mm 0.25 1.7
EWC0608C SS-EWC0608C 6 mm 10 mm 10.4 mm 8 mm 0.44 1.7
EWC0608XA SS-EWC0608XA 6 mm 10 mm 10.4 mm 7.5 mm 0.25 1.7
EWC0608XC SS-EWC0608XC 6 mm 10 mm 10.4 mm 7.5 mm 0.44 1.7
EWC0809A SS-EWC0809A 8 mm 12 mm 12.4 mm 9 mm 0.49 2.4
EWC0809C SS-EWC0809C 8 mm 12 mm 12.4 mm 9 mm 0.88 2.4
EWC0812A SS-EWC0812A 8 mm 14.2 mm 15 mm 12 mm 1.18 5.8
EWC0812C SS-EWC0812C 8 mm 14.2 mm 15 mm 12 mm 1.96 5.8
EWC1010A SS-EWC1010A 10 mm 16 mm 17 mm 10 mm 1.18 6
EWC1010C SS-EWC1010C 10 mm 16 mm 17 mm 10 mm 1.96 6
EWC1012A SS-EWC1012A 10 mm 16 mm 17 mm 12 mm 1.37 6.8
EWC1012C SS-EWC1012C 10 mm 16 mm 17 mm 12 mm 2.35 6.8

OWC..GXRZ
Miniature One-Way Clutch  with Clockwise Rotation Direction
METRIC Sizes for shaft sizes from
 3 mm to 10 mm
CLI Dimension (mm) Torque Rating Backlash Weight (g)
Bearing No. d D1 B (N.m)
OWC307GXRZ 3 7.2 5.4 0.13 4 1.10
OWC408GXRZ 4 8 6 0.15 4 1.70
OWC410GXRZ 4 10 5.4 0.30 3.5 2.14
OWC511GXRZ 5 11 5.4 0.60 3 2.34
OWC610GXRZ 6 10.2 8 0.54 3 2.55
OWC612GXRZ 6 12 5.4 0.80 3 2.75
OWC6128.4GXRZ 6 12 8.4 0.80 3 2.82
OWC812GXRZ 8 12.2 8 0.73 3 3.30
OWC814GXRZ 8 14 5.4 1.10 2 3.37
OWC8148.4GXRZ 8 14.3 8.4 1.47 3 3.80
OWC1016GXRZ 10 16 5.4 1.50 1 4.02

CSK..P
Sprag Keyway Type One Way Clutch Bearings
One Way Overrunning Sprag Freewheel Cam Clutch Bearings
 for
shaft sizes from
12 mm to 40 mm
CLI Dimension
(mm)
Torque Limiting Speed
(RPM)
Load
Rating
Weight
Bearing No. d D L N.m Dynamic(C) Static(Co) (KN) Kg
CSK12P 12 32 10 9.3 10000 6.1 2.77 0.04
CSK15P 15 35 11 17 8400 7.4 3.42 0.06
CSK17P 17 40 12 30 7350 7.9 3.8 0.07
CSK20P 20 47 14 50 6000 9.4 4.46 0.11
CSK25P 25 52 15 85 5200 10.7 5.46 0.14
CSK30P 30 62 16 138 4200 11.7 6.45 0.21
CSK35P 35 72 17 175 3600 12.6 7.28 0.3
CSK40P 40 80 22 325 3000 15.54 12.25 0.5

CSK..P-2RS
Sprag Keyway Type One Way Clutch Bearings
One Way Overrunning Sprag Freewheel Cam Clutch Bearings
 for
shaft sizes from
12 mm to 40 mm
CLI Dimension
(mm)
Torque Limiting Speed
(RPM)
Load Rating Weight
Bearing No. d D L N.m Dynamic(C) Static(Co) (KN) Kg
CSK12P-2RS 12 32 14 9.3 10000 6.1 2.77 0.05
CSK15P-2RS 15 35 16 17 8400 7.4 3.42 0.07
CSK17P-2RS 17 40 17 30 7350 7.9 3.8 0.09
CSK20P-2RS 20 47 19 50 6000 9.4 4.46 0.145
CSK25P-2RS 25 52 20 85 5200 10.7 5.46 0.175
CSK30P-2RS 30 62 21 138 4200 11.7 6.45 0.27
CSK35P-2RS 35 72 22 175 3600 12.6 7.28 0.4
CSK40P-2RS 40 80 27 325 3000 15.54 12.25 0.6

CSK..PP
Sprag Keyway Type One Way Clutch Bearings
One Way Overrunning Sprag Freewheel Cam Clutch Bearing

Metric Size for shaft sizes from 15 mm to 40 mm
CLI Dimension
(mm)
Torque Limiting Speed
(RPM)
Load Rating Weight
Bearing No. d D L N.m Dynamic(C) Static(Co) (KN) Kg
CSK15PP 15 35 11 2 0.6 17 7.4 3.42
CSK17PP 17 40 12 2 1 30 7.9 3.8
CSK20PP 20 47 14 3 1.5 50 9.4 4.46
CSK25PP 25 52 15 6 2 85 10.7 5.46
CSK30PP 30 62 16 6 2 138 11.7 6.45
CSK35PP 35 72 17 8 2.5 175 12.6 7.28
CSK40PP 40 80 22 10 3 325 15.54 12.25



Home
