Rolling Ball Bearings-Miniature Ball Bearings-Flanged miniature ball bearings, CHROME STEEL AISI52100, INCH sizes

Original miniature bearings flanged chrome 402
Product Picture
Original 2 flanged miniature ball bearings chrome steel aisi52100 nw
Download PDF Catalogue

Flanged miniature ball bearings - CHROME STEEL AISI52100
INCH size



CLI flanged inch sized miniature bearings have a solid steel flange on the outer ring. This allows the bearing to be more easily located in a housing. The flange can also help to prevent axial movement of the bearing in the event of a thrust load on the bearing.

It is easier to maintain the position of a flanged bearing in the housing where a lot of vibration is present. Flanged bearings are sometimes used where the housing is made from a different material and may expand more than the bearing outer ring at higher temperatures. The resulting loose fit may allow a non-flanged bearing to move within the housing.

CLI flanged chrome steel bearings, with a steel retainer and a suitable lubricant, can be used at temperatures of 120°C constant or up to 150°C intermittent. Above these temperatures, the load capacity of chrome steel is reduced and the steel undergoes more of a dimensional change than stainless steel.

Plese select the bearings in the following tables. Click " CLI BEARING NO. " or " DETAILS " to check the specifications...

BEARING LIST & BEARING DETAILS

AISI52100 chrome steel flanged miniature bearings
for shaft sizes from
0.125" to 0.625"




BORE

(Inch)

O.D.

(Inch)

OPEN BEARING (No Suffix)

SHIELDED BEARING (2RS)

SEALED BEARING (ZZ)

WIDTH

(Inch)

CLI BEARING

NO.

DETAILS

WIDTH

(Inch)

CLI BEARING

NO.

DETAILS

WIDTH

(Inch)

CLI BEARING

NO.

DETAILS

0.125

0.375

0.1562

FR2

DETAILS

0.1562

FR2ZZ

DETAILS

0.1562

FR2-2RS

DETAILS

0.1875

0.3125

0.1094

FR156

DETAILS

0.125

FR156ZZ

DETAILS







0.5

0.1562

FR3

DETAILS

0.196

FR3ZZ

DETAILS

0.196

FR3-2RS

DETAILS

0.25

0.375

0.125

FR168

DETAILS

0.125

FR168ZZ

DETAILS







0.5

0.125

FR188

DETAILS

0.1875

FR188ZZ

DETAILS







0.625

0.196

FR4

DETAILS

0.196

FR4ZZ

DETAILS

0.196

FR4-2RS

DETAILS

0.375

0.875

0.2188

FR6

DETAILS

0.2812

FR6ZZ

DETAILS

0.2812

FR6-2RS

DETAILS

0.5

1.125

0.25

FR8

DETAILS

0.3125

FR8ZZ

DETAILS

0.3125

FR8-2RS

DETAILS

0.625

1.375

0.2812

FR10

DETAILS

0.3438

FR10ZZ

DETAILS

0.3438

FR10-2RS

DETAILS
