•  Ceramic balls are spherical, rolling elements that provide higher stiffness, lower thermal expansion, lighter weight, increased corrosion resistance, and higher electrical resistance than steel balls. They are made from a variety of ceramic materials.

•  CLI Bearing provide a wide range of ceramic ball options across a variety of sizes. Material options include Silicon nitride (Si3N4), Zirconia (ZRO2), Alumina (Al2O3) and Silicon carbide (SIC) from 0.4mm to just over 115mm in diameter with the most common sizes in between. Precision grades provided are G5, G10, G16, G25 and G100 grades.

•  Different ceramic material have different properties, here is the introduction of ceramic materials and their properties.

•  Manufacturing Proccess of Ceramic Balls

Pictures	Ceramic Balls & Materials
Basic Info	ZrO2 ball	Si3N4 ball	SiC ball	Al2O3 ball
Density	6.0 g/cm	3.2 g/cm	3.15 g/cm	3.93 g/cm
Color	White	Black	Black	Ivory
Grade	G5 to G2000	G5 to G2000	G10 to G2000	G5 to G2000
Ball Size (Diameter )	Φ= 0.5 mm to 35 mm Φ= 1/32" to 2"	Φ= 0.5 mm to 35 mm Φ= 1/32" to 2"	Φ= 0.5 mm to 35 mm Φ= 1/32" to 2"	Φ= 0.5 mm to 35 mm Φ= 1/32" to 2"

•  Ceramic Ball Grades:

•  Typical applications for these grades are as followings:

•  There are a variety of different ceramic materials, each with their own capabilities, advantages and disadvantages; their use in bearing and rolling element applications was pioneered by many of the space agencies and continues to be at the forefront of engineering technology.

Plese select the bearings in the following tables. Click " CLI BEARING NO. " or " DETAILS " to check the specifications...
